產(chǎn)品特點(diǎn)
產(chǎn)品應用
產(chǎn)品參數
| MODEL | MPEX-J106 | MPEX-J106E | MPEX-J110 | MPEX-J110E |
| Feeding capacity (t/h) | 500 | 500 | 600 | 600 |
| Feeding height (mm) | 4,150
| 4,200 | 4,150 | 4,150 |
| Hopper volume (m3) | 4 | 5 | 5 | 5 |
| Jaw crusher modle | C106 | C106 | C116 | C116 |
| Crusher inlet (L*W) (mm) | 1,060*700 | 1,060*700 | 1,150*760 | 1,150*760 |
| Max feede size (mm) | 560 | 560 | 610 | 610 |
| Gap width adjustment range (mm) | 70-200 | 70-200 | 70-200 | 70-200 |
| Crusher weight (kg) | 14,500 | 14,500 | 21,000 | 21,000 |
| Engine power (kW) | 97 | 200 | 97 | 250 |
| Total weight (kg) | 47,000 | 50,000 | 53,000 | 55,000 |
| Transport size (mm) (L*W*H) | 15,500*3,700*3,800 | 17,500*3,700*3,800 | 17,200*3,800*3,880 | 17,200*3,800*3,880 |
| Crusher power（kw） | 110 | 110 | 132 | 132 |
